OWON XDS3062A 60MHZ 1GS/s Oscilloscope datalogger multimeter＋1CH 25M Waveform Generator + Battery

The Owon XDS3062A 60MHz High Resolution 12-bit Digital storage oscilloscope has 16 times the sensitivity of normal 8-bit scopes. It samples at 1 GSa/s, has a huge 40Mpt sample record length and an 8” 800 x 600 high resolution LCD display. It offers low background noise, and a vertical sensitivity of 1 mV/div - 10 V/div. This third generation design XDS3062A has multiple additional options (available on request with additional costs ): touch-screen (additional costs $45.00 ), etc. 12-bit high resolution ADC shows waveforms in detail 60 MHz bandwidth, 1GS/s sample rate low background noise, vertical sensitivity in 1 mV/div - 10 V/div 3rd generation technology platform - Xvisual 8-inch 800 x 600 high resolution LCD 40Mpt memory Features: Super Performance: 12bit high resolution ADC, restoring the waveform detail fully 40M record length, and 75,000 wfms/s waveform refresh rate Low background noise, vertical sensitivity in 1 mV/div - 10 V/div Multi- trigger, and bus decoding function SCPI, and LabVIEW supported Creative New Look: Ultra-thin body-design, less space accommodation Multi-interface integration - USB host, USB device, USB port for PictBridge, LAN, AUX, and more VGA port - better solution for video expansion, and teaching demonstration 8 inch 800 x 600 high resolution touchscreen LCD n-in-1: Functions as data logger, and multimeter with data logging function Dual-channel 25MHz / 50MHz arbitrary waveform generator Portable design, supports Battery pack($50.00 additional) , and WiFi module ($55.00 additional) Package includes: 1 - Power Cord 1 - USB Cable 2 - Oscilloscope Probe 1 - Probe Adjust Tool 1 - CD Rom 1 - User's Manual

• MODEL :XDS3062AMBAG21
• Dual-channel 25MHz / 50MHz arbitrary waveform generator Portable design, supports Battery pack, and WiFi module (battery and WIFI are the options with additional cost)
• Low background noise, vertical sensitivity in 1 mV/div - 10 V/div
