Load Cell, YZC-516C S type weighing sensor 100kg 200kg 300kg 500kg 2000kg 1Ton 1.5Ton 2Ton 1T pull pressure sensor weight sensor load cell,Test Tension(Indicator)
Product details
| Management number | 247342068 | Release Date | 2026/08/16 | List Price | US$89.78 | Model Number | 247342068 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Rated output Accuracy 2.0±0.004mV/V C2-C3 Maximum degree of calibration 3000Nmax Minimum.Rated output accuracy 2.0 ±0.004mV/V. C2-c3 Maximum degree of calibration 3000Nmax Minimum degree of calibration Emax/7500 <;±0.02%RO Creep Creep0.02%RO/30min Temperature effect on sensitivity drift sensitivity0.0016%RO/℃>Temperature effect on zero0.002%RO/℃ Zero balanceXIN NUO QI±1.0%ROinput impedance resistance365±5ΩOutput resistance Insulation resistance5000ΜΩ(50V)Recommended excitation voltage. Output resistance350+5Ω> Insulation Resistance5000 μω (50V) Recommended excitation voltage 10-15V> temperatureCompensation range -10-+40 ° C > Operating temperature range-35~+80 ° C > Safe Overload capability overload150%RO> Ultimate overload200%RO
- Safe and anti‑explosive product, can be used in bad environment and hazardous areas
- Oil‑proof, waterproof and anti‑corrosion, suitable for all kinds of environments
- Suitable for mixing station, batching machine, asphalt station, etc
- Design. Precise and stable. Easy installation
- Versatile and Easy to Install: for various applications such as mixing stations, batching machines, and asphalt stations, this load cell offers a hassle-free installation process. Its allows for easy integration into your existing systems, saving you time and effort
| ASIN | B0DJK41P6P |
|---|---|
| Size | 1 |
| Color | Indicator |
| Item Weight | 1.76 ounces |
| Part Number | 5287657242 |
| Manufacturer | LJIA |
| Power Source | ac |
| Number Of Pieces | 1 |
| Item model number | 5287657242 |
| Package Dimensions | 1.18 x 0.79 x 0.39 inches |
| Item Package Quantity | 1 |
